RSB-3430 Testing method (RSB-3430 測試方法)

 Note: RS-232: /dev/ttymxc2
 GPIO : need to connect loopback.
 RS-485: pin1 data- & pin2 data+ (ttyUSB0)

RS-232

$ stty -F /dev/ttymxc2 -echo -onlcr 115200 crtscts
$ cat /dev/ttymxc2 &
$ echo "Serial Port Test" > /dev/ttymxc2

RS485

Test RS-485 with Adam-4520.

$ stty -F /dev/ttyUSB0 115200
$ echo "Serial Test" > /dev/ttyUSB0

GPIO

[EXTENSION I/O B]
pin#5: gpio 121, pin#6: gpio 122
pin#7: gpio 123, pin#8: gpio 124
pin#9: gpio 125, pin#10: gpio 126
pin#11: gpio 127, pin#12: 133

RSB-3720 Testing method (RSB-3720 測試方法 )

RS-232(COM3):

# stty -F /dev/ttymxc1 -echo -onlcr 115200
# cat /dev/ttymxc1 &
# echo "Serial Port Test" /dev/ttymxc1

RS-485

Note:

Adam-4520
Data- : Pin1
Data+ : Pin2
Remember to set up RS-485 before test.

# stty -F /dev/ttyUSB0 speed 115200 ignbrk -brkint -icrnl -imaxbel -opost -onlcr -isig -icanon -iexten -echo -echoe -echok -echoctl -echoke
# cat /dev/ttyUSB0 &
# echo "Serial Test" > /dev/ttyUSB0

GPIO

Note:
input pin#5: gpio 504(DB9-1)
output pin#6: gpio 505(DB9-6)
input pin#7: gpio 506(DB9-2)
output pin#8: gpio 507(DB9-7)
input pin#9: gpio 508(DB9-3)
output pin#10: gpio 509(DB9-8)
input pin#11: gpio 139(DB9-4)
output pin#12: gpio 138(DB9-9)

# echo 504 > /sys/class/gpio/export
# echo 505 > /sys/class/gpio/export
# echo out > /sys/class/gpio/gpio2/direction
# echo in > /sys/class/gpio/gpio1/direction
# cat /sys/class/gpio/gpio1/value
# echo 1 > /sys/class/gpio/gpio2/value
# cat /sys/class/gpio/gpio1/value

RTENOTITLE

# echo 506 > /sys/class/gpio/export
# echo 507 > /sys/class/gpio/export
# echo out > /sys/class/gpio/gpio4/direction
# echo in > /sys/class/gpio/gpio3/direction
# cat /sys/class/gpio/gpio3/value
# echo 1 > /sys/class/gpio/gpio4/value
# cat /sys/class/gpio/gpio3/value

RTENOTITLE

# echo 508 > /sys/class/gpio/export
# echo 509 > /sys/class/gpio/export
# echo out > /sys/class/gpio/gpio6/direction
# echo in > /sys/class/gpio/gpio5/direction
# cat /sys/class/gpio/gpio5/value
# echo 1 > /sys/class/gpio/gpio6/value
# cat /sys/class/gpio/gpio5/value

RTENOTITLE

# echo 139 > /sys/class/gpio/export
# echo 138 > /sys/class/gpio/export
# echo out > /sys/class/gpio/gpio8/direction
# echo in > /sys/class/gpio/gpio7/direction
# cat /sys/class/gpio/gpio7/value
# echo 1 > /sys/class/gpio/gpio8/value
# cat /sys/class/gpio/gpio7/value

RTENOTITLE



Test
